F3RE035A

F3 RE 035/A is a retractable tail-lift semi-automatic for installation under panel vans. The box that contain the lift is produced in aluminium with reduced dimensions that allow installation on a wide range of vans such as:

Benefits:
  • arrow Volkswagen Crafter L2, L3
  • arrow Renault Master L2, L3
  • arrow Fiat Ducato L2, L3, L4
  • arrow Opel Movano L2, L3
  • arrow Ford Transit L2, L3
  • arrow Citroen Jumper L2, L3, L4
  • arrow Peugeot Boxer L2, L3, L4
  • arrow Nissan NV 400 L2, L3
  • arrow Man TGE L2, L3
  • arrow Mercedes Benz Sprinter L2, L3

Provided by:

  • Battery Disconnect Device With Key Main Switch;
  • Emergency Mechanical Hand Pump;
  • Toe Guard Protection Bridge Plate;
  • Automatic Safety Flap on Platform Tip.

Suggested options

Benefits:
  • arrow Radio remote control.
Specification Details
Platform Aluminium
Platform depth 1200 mm deep, 830 mm wide
Tilt cylinders 2
Sliding system Electric deployment and stowage
Power supply 12 V
Weight 140 Kg
